Dual VMS EF System with Bracket - Sprinter Van - Dual 400C EF VMS System with Bracket

Part Number: 80170
$784.50
$784.50
Dual VMS EF System with Bracket - Sprinter Van Dual VMS EF System with Bracket - Sprinter Van
Video Thumbnail Dual VMS EF System with Bracket - Sprinter Van
Dual VMS EF System with Bracket - Sprinter Van
Dual VMS EF System with Bracket - Sprinter Van
Video Thumbnail Dual VMS EF System with Bracket - Sprinter Van

Dual VMS EF System with Bracket - Sprinter Van - Dual 400C EF VMS System with Bracket

Part Number: 80170
$784.50
$784.50
Shipping calculated at checkout.

Dual 400C & 444C VMS EF System with bracket for 2019+ Sprinter Van!

We've enhanced our VMS Sprinter systems by adding EF (Enhanced Flow) technology. EF technology started life with our portables and is now integrated into our Sprinter Van air management system. Delivering up to 21% faster fills and 36% more performance on Dual 400C-EF and up to 32% faster fills and 27% more performance on Dual 444C-EFVIAIR Dual Mounted Systems (VMS EF) are high-performance onboard air systems designed to provide high CFM and fast tire fill with unsurpassed durability. These kits come with all components necessary to install a fully functioning system. A vehicle-specific bracket provides an easy mounting platform in the engine bay of your Sprinter Van. VMS can be used for tire inflation, air tools, air horns, air lockers, air bags and inflatables of all kinds.

400C-EF Dual (150 PSI/5.30CFM): Ideal for tire inflation management and any inflation tasks where 150PSI is needed. Reliable, fills fast, and compact. 100% Duty Cycle @ 40 PSI. Available in with Black Compressors only.

444C-EF Dual (200 PSI/4.59 CFM): Ideal for tire inflation management, air suspension, and general needs where 200PSI is needed. Reliable and affordable. 100% Duty Cycle @ 100PSI. Available with Black compressors only

Dual VMS EF System with Bracket - Sprinter Van

What’s in the Box

Specifications

Performance

SPECS - DUAL 400C-EF VMS Sprinter System

  • 5.30 CFM @ 0 PSI
  • 12-Volt
  • Permanent Magnetic Motor
  • Duty Cycle: 33% @ 100 PSI / 100% @ 40 PSI
  • Max. Working Pressure: 150 PSI
  • Max. Amp Draw: 64-Amps
  • Ingress Protection Rating: IP67
  • Max. Ambient Temp: +158F
  • Max. Ambient Temp: -40F
  • Dimensions: 9.5" x 3.9" x 6.8" (each unit)
  • Net Weight: 17.60 Lbs. (compressors only)

FEATURES - DUAL 400C-EF VMS Sprinter System

  • (2) 400C-EF Stealth Black Air Compressors
  • Redesigned EF head improves airflow and heat management
  • Upgraded internals for increased flow and durability
  • Complete dual wiring harness w/ 70A fuse holder and 35A micro relays
  • Air locker compatible
  • Sealed compressor with IP rating of IP67 (Waterproof/Dustproof)
  • Designed to be air tank ready (Air tank Optional)
  • 8-port Billet Manifold
  • Pro Series Air Source Relocation Kit
  • Illuminated Rocker Switch

SPECS - DUAL 444C-EF VMS Sprinter System

  • 4.59 CFM @ 0 PSI
  • 12-Volt
  • Permanent Magnetic Motor
  • Duty Cycle: 100% @ 100 PSI / 50% @ 200 PSI
  • Max. Working Pressure: 200 PSI
  • Max. Amp Draw: 54-Amps
  • Ingress Protection Rating: IP67
  • Max. Ambient Temp: +158F
  • Max. Ambient Temp: -40F
  • Dimensions: 11.4" x 4.1" x 6.8" (each unit)
  • Net Weight: 21.70 Lbs. (compressors only)

FEATURES - DUAL 444C-EF VMS Sprinter System

  • (2) 444C-EF Stealth Black or Chrome Air Compressors
  • Redesigned EF head improves airflow and heat management
  • Upgraded internals for increased flow and durability
  • Complete dual wiring harness w/ 70A fuse holder and 35A micro relays
  • Air locker compatible
  • Sealed compressor with IP rating of IP67 (Waterproof/Dustproof)
  • Designed to be air tank ready (Air tank Optional)
  • 8-port Billet Manifold
  • Pro Series Air Source Relocation Kit
  • Illuminated Rocker Switch

400C-EF / 12-VOLT COMPRESSORS - Supply Voltage 13.8 Volts

444C-EF / 12-VOLT COMPRESSORS - Supply Voltage 13.8 Volts
